EXTRA HEAVY DUTY OIL COUNTRY CHUCKS
4-JAW INDEPENDENT CHUCKS


Extra Heavy Duty Oil Country 4 Jaw Independent Chucks
FEATURES:

  • Solid Steel Body
  • American Standard Tongue & Groove master jaws

Extra Heavy Duty Oil Country Chucks

4-Jaw Independent - Hardened Top Reversible Jaw


24 " & 32 " Steel Body Chucks
Master jaw and hardened reversible top jaw styling up to 13” thru hole capacity for large, heavy duty applications. Competitively priced, these chucks provide top quality, serviceability and dependability with a name you can trust for demanding work.
Diagram of Extra Heavy Duty Oil Country 4 Jaw Independent Chuck


Technical Data

Oil Country 4-Jaw Independent Chuck
  Part No. A B C D E F, G H J K L M N P R RPM Weight Lbs.
24" IND24R 24.8 10.5 11.22 4.25 16.97 7/8-9x5 7.87 3.35 5 2.56 0.25 1.26 0.55 1.18 850 678
32" IND32R 31.5 13.11 14.96 4.69 16.5 N/A 8.5 3.35 5 2.56 0.86 1.57 0.71 1.5 450 772
